When clicking on the length tool, a dialog opens and the desired length can be put in. The same can be done with a line.Įach length of the side is now easily defined by selecting it with the mouse: selected item turns into green.
The sides of the triangle follow the vertex. A vertex can be touched with the mouse and dragged around. the vertices of this different drawing elements are constrained to an identical location. The red dot beneath the drawing pointer indicates a coincidence constraint between two vertices, i.e. They are set automatically at clicking at this location. Those symbols that appear beneath the drawing pointer do indicate auto-constraints. This will make sure that the last vertex is identical to the first one and the profile is closed. A red point should be visible near the mouse pointer before clicking. So for the last line a click is needed on the first created vertex. Each click in the drawing plane sets a vertex. In the Sketcher it is ok to draw an arbitrary triangle with the polyline tool and define its properties in a later step. A grid with a coordinate system will be shown with a red point at the origin. A new empty sketch will be created and opened in edit mode. It doesn't matter in this case, so the xy-plane can be confirmed. A dialog appears, where the orientation of the new sketch in the 3D-space can be selected. The sketcher workbench has to be selected:Ī new sketch will be created by clicking at. When there is no open document, a new one will be created by clicking on. In order to understand the difference, it is best to construct a triangle by yourself.Īn open document is needed in order to make a sketch. The formulas and the above helper constructions are not needed. Those are needed, if the triangle has to be defined by pre-calculated coordinates. The wikipedia:Triangle page shows a collection of formulas to calculate the missing information in order to draw a triangle from the minimum specification. draw the missing two sides from the endpoints of the base line to the crossing point of the two circles or the calculated vertex.make two circles with a radius given by the other two side lengths, or alternatively calculate the coordinates of the third vertex.In order to construct a triangle from 3 lengths in the traditional way, the following has to be done: The one exception is three angles, which will not define the size.
A triangle is fully defined by 3 values, which can be any from the following list: side length, angle, height, area. A way to show the difference is the construction of a triangle.
The sketcher is different to traditional drawing tools. The Sketcher is a tool to generate 2D-objects for usage in parts design.
